injury to the user or may damage the system in the event of a

fall. If you are not sure that you have enough Clear Fall Distance

or have concerns about objects in the fall path – stop

immediately and seek the guidance of a competent person or

contact FallTech for Technical Support.

3. Carefully inspect the EcoAnchors to ensure that they are

undamaged and in serviceable condition (see Section 8 of this

manual for complete inspection details.

4. Spread the EcoAnchor bladders out flat, maximizing surface

contact. They should be spaced apart so that the distance

between the anchor rings is equal to the working span of the

Checkline horizontal lifeline. Ensure they are positioned as

indicated on the labels with the vents at the highest corner and

with the drains at the lowest point (see Fig. 3.2). The vents allow

air to escape and prevents over-pressurizing. Incorrect

positioning can result in trapped air and under-filling,

making the anchor unsafe.

5. Fill the EcoAnchors with water by removing the caps from the fill

valve hoses and then inserting the fill-valve hoses inside a

standard garden hose (see Fig. 3.1). The EcoAnchors are full

when water begins to flow from the vent valves, which are on the

opposite corners (diagonal from the fill valves). Detach the hose

and seal the fill valve. The EcoAnchors should now be filled to

capacity. Any air trapped in the bladder can be exhausted

through the vent.

6. Check the EcoAnchors for leaks and ensure that they are

positioned correctly on the anchor surface. Install the Checkline

4-User THLL (temporary horizontal lifeline) Kit by attaching the

swivel end of the horizontal lifeline to the anchor ring on top of

one of the EcoAnchors using the carabiner provided in the kit.

Then attach the tensioner end of the horizontal lifeline to the

anchor ring on top of the second EcoAnchor with the carabiner

provided in the kit. Adjust the tensioner as directed in

Section 3.1 of your Checkline THLL Instruction Manual.

7. Ensure your Full Body Harness is properly donned and adjusted

and that your connecting device is securely attached to your

back D-ring. Ensure your connecting device is securely attached

to the Checkline Temporary HLL System.

8. Proceed cautiously with your work. Do not run, jump or over-

reach. The EcoAnchors and the Checkline HLL are elastic and

will flex and bounce if you pull against it when you reach the

working limit of your connecting device. Move with care and

deliberation at all times while working at heights. Failure to

do so may result in a fall.

9. Do not allow your connecting device to pass under your arm or

between your legs – severe injury or death may result. Also

avoid sharp edges which may damage your connecting device in

the event of a fall.

10. If you are tied-off at the foot-level, or in a manner that will allow

more than six feet of free fall, ensure that your connecting device

is rated for extended free falls (free falls greater than six feet).

Once the above steps have been taken, the user will have access to

their work area while walking and moving at normal speeds. It is

important not to make sudden or dramatic movements! When using this

system, care must be taken to be aware of the work environment and

any hazards, obstructions or obstacles that may exist. Be careful of any

and all fall hazards and also be aware of slipping and tripping hazards as

well.

NOTE: Do not attempt to use any fluid or substance other than common

tap water to fill the bladder of your EcoAnchor. Do not attempt to use

antifreeze or any other additive.

Warning: Once your EcoAnchor(s) have been placed on the

working surface and filled, do not attempt to lift, move or hoist the

EcoAnchor while it is filled with water – severe damage may result.

To empty and remove the EcoAnchor and Checkline HLL Kit from the

working location, remove the HLL from the EcoAnchors and stow in the

storage bag provided with the kit. Open the drain-valves (see Fig. 3.3)

and allow the water to drain from the bladders. Once they are nearly

empty, lift up the bladders from the corners opposite the drain valves to

help the remaining water drain out. Fold the bladders twice (so that they

are 1/3 their normal width) and roll them up into tight bundles. Stow the

bladders in the storage bags and keep in a cool dry location.

3.6: Installation and Use – EcoAnchor with PSR 2-User THLL Kit

A pair of EcoAnchors may be used as anchorages for the FallTech 2-

User PSR Temporary Horizontal Lifeline as well. In this configuration, a

pair of EcoAnchors (model # 7433) can be used in conjunction with the

770003 30’ PSR HLL or the 770006 60’ PSR HLL. The 770001 100’

PSR HLL shall not be used with the EcoAnchor.

The Falltech PSR 2-User Temporary Horizontal Lifeline comes

with its own instruction manual. The user(s) and installer(s) of this

system must read and adhere to both the PSR and the EcoAnchor

instruction manuals in order to safely install and use system.

Failure to do so may result in serious injury or death.
